Semi Automatic Detergent Powder Production Line For Chemical Industry

Semi Automatic Detergent Powder Production Line For Chemical Industry

Detergent Powder Production Line Description

1. Process configurations from simple manual operations to centralized automation of central computers can be designed. We also undertake technical consulting and old line engineering services. Adopt the process of high spray tower. Apparent specific gravity of product is 0.25~0.50g/cm3.All kinds of powder materials, liquid materials are weighed respectively according to the formula, , sent to slurry preparator to make slurry, after hydrated aging, crushing and filtering by aging system, sent to the top of spray tower by high pressure pump. Form mist particles through spray nozzles, dried by hot air generated by hot air furnace. At the bottom of the tower, hollow particles of detergent powder are formed. Then by air lifting, aging, base powder is made. After sieving, other materials (such as enzyme, color particles, essence, non-ionic, etc.) shall be added into base powder, and then put together into the post-blending mixer. After mixing and granulating, final detergent power in medium & top grade is made, and eventually packing.

Detergent Powder Production Line Technology Characteristics

1. Powder raw materials fed into tank in certain ratio automatically according to computer control

2. Distribute structure and multi-interface network ability easy to use.

3. Automatically controlled system which is suitable for large scale industrial control and visualization of the whole process of production

4. Semi-automatic and full automatic production line from 1T/hour to 30 T/hour

5. Workshop environment is provided with perfect dedustion system,ensure the workshop environment as clean as top level of Unilever,Henkel ,P&G

Detergent Powder Production Line attributes
