High Speed Sodium Silicate Production Equipment Wet Method 10 Ton / Day

High Speed Sodium Silicate Production Equipment Wet Method 10 Ton / Day

  • High Speed Sodium Silicate Production Equipment Wet Method 10 Ton / Day
High Speed Sodium Silicate Production Equipment Wet Method 10 Ton / Day
Product Details:
Place of Origin: Zhejiang, China
Brand Name: Meibao
Certification: ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: Negotiable
Packaging Details: Standard packing or as customer requirements
Delivery Time: 40 days
Payment Terms: L/C, T/T
Supply Ability: 3 sets/month
Contact Now
Detailed Product Description
Product Name: Sodium Silicate Production Equipment Application: Daily Chemical
Process: Wet Method Funcation: Reaction Kettle
Control: PLC Control Capacity: 10 Ton / Day
Material: SS 304 / 316L Molar Ratio: Below 2.5
High Light:

sodium silicate plant machinery

,

sodium silicate production plant

,

High Speed Sodium Silicate Production Equipment

High Speed Sodium Silicate Production Equipment Wet Method 10 Ton / Day



Sodium Silicate Production Equipment  Description



Put liquid caustic soda into slurry preparator after weighing and start mixing. Then put quartz sand into slurry preparatorafter weighing. The liquid and solid two phase materials are stirred to a balanced suspension.
Use sand pump send mixture to reaction kettle, add steam until reach setting pressure then stop adding. The whole process is exothermic reaction, and the modulus of the material can be sampled at the time reaction stopped, if the modulus is not qualified, keep reacting to the desired modulus. Discharge steam first, use the residual pressure to discharge the material into the middle tank. Use steam to heat liquid caustic soda and materials in batching tank, heat can be fully used, save the energy.
Add water into middle tank in proportion to reach needed concentration, precipitate based on setting time.
The clarified liquid is fully settled through the thick liquid pump to press filter, to obtain the sodium silicate, then use the pump transfer to the finished product storage tank.
Precipitate in the middle tank will self flow back to batching tank.
Filtered slag washing with clean water several times to neutral PH, collect together and send to solid waste treatment center or make bricks.The amount of slag is small, to produce one ton liquid sodium silicate will make about 2~3kg slag. The cleaning water will bake to batching section.

Sodium Silicate Production Equipment Technology characteristics


Wet method Sodium Silicate production line is simple, low energy consumption, small labor intensity, easily getting raw materials,low investment. The Sodium Silicate produced by the wet phase is clear and transparent. According to the different modulus of Sodium silicate, it can be used as the basic raw material of chemical industry in general casting, precision casting, paper making, ceramics, clay, mineral processing, kaolin, washing and so on.The market potential is great and the benefit.



Sodium Silicate Production Equipment attributes



Product name High Speed Sodium Silicate Production Equipment Wet Method 10 Ton / Day
Process Wet Method
Application Daily chemical,casting, clay, mineral processing
Capacity >10 ton/day
Usage Produce liquid sodium silicate
Material SS 304 / 316L
Control PLC control
Intallation Engineer Guide



High Speed Sodium Silicate Production Equipment Wet Method 10 Ton / Day 0



Company Introduction



Our company is a "National High-tech Enterprise". It is a member of China washing Association Technical Equipment Specialized Committee and has the autonomy of import and export business. We have a complete product research and development system,quality management system and professional engineering construction team. Our company has passed ISO9001 international quality management system certification. Many of the company's technologies and equipment have applied for national invention and utility model patents.



High Speed Sodium Silicate Production Equipment Wet Method 10 Ton / Day 1
