Name: Wet Method Liquid Sodium Silicate Plant Machinery Small Labor Intensity
Brand: Zhejiang Meibao Industrial Technology Co.,Ltd
SKU: MB-SF
Price: Negotiable USD
Availability: InStock

Home Products Sodium Silicate Production Equipment

Wet Method Liquid Sodium Silicate Plant Machinery Small Labor Intensity

Product Details:

Place of Origin:	Zhejiang, China
Brand Name:	Meibao
Certification:	ISO9001
Model Number:	MB-SF

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiable
Packaging Details:	Standard packing or as customer requirements
Delivery Time:	40 days
Payment Terms:	L/C, T/T
Supply Ability:	3 sets/month

Contact Now

Detailed Product Description

Product Name:	Sodium Silicate Production Equipment	Application:	Daily Chemical
Process:	Wet Method	Function:	Reaction Kettle
Control:	PLC Control	Capacity:	10 Ton / Day
Material:	SS 304 / 316L
Highlight:	sodium silicate plant machinery , sodium silicate production plant , 10 Ton / Day Sodium Silicate Plant Machinery

Simple Operation Wet Method Liquid Sodium Silicate Production Line

Sodium Silicate Production Equipment Description

Put liquid caustic soda into slurry preparator after weighing and start mixing. Then put quartz sand into slurry preparatorafter weighing. The liquid and solid two phase materials are stirred to a balanced suspension.

Use sand pump send mixture to reaction kettle, add steam until reach setting pressure then stop adding. The whole process is exothermic reaction, and the modulus of the material can be sampled at the time reaction stopped, if the modulus is not qualified, keep reacting to the desired modulus. Discharge steam first, use the residual pressure to discharge the material into the middle tank. Use steam to heat liquid caustic soda and materials in batching tank, heat can be fully used, save the energy.

Add water into middle tank in proportion to reach needed concentration, precipitate based on setting time.

The clarified liquid is fully settled through the thick liquid pump to press filter, to obtain the sodium silicate, then use the pump transfer to the finished product storage tank.

Precipitate in the middle tank will self flow back to batching tank.

Filtered slag washing with clean water several times to neutral PH, collect together and send to solid waste treatment center or make bricks.The amount of slag is small, to produce one ton liquid sodium silicate will make about 2~3kg slag. The cleaning water will bake to batching section.

Sodium Silicate Production Equipment Technology characteristics

Wet method Sodium Silicate production line is simple, low energy consumption, small labor intensity, easily getting raw materials,low investment. The Sodium Silicate produced by the wet phase is clear and transparent. According to the different modulus of Sodium silicate, it can be used as the basic raw material of chemical industry in general casting, precision casting, paper making, ceramics, clay, mineral processing, kaolin, washing and so on.The market potential is great and the benefit.

Sodium Silicate Production Equipment attributes

Product name	Simple Operation Wet Method Liquid Sodium Silicate Production Line
Process	Wet Method
Application	Chemical industry
Capacity	min10 ton/day
Key equipment	Reaction kettle, filer press, etc
Intallation	Engineer Guide

Wet Method Liquid Sodium Silicate Plant Machinery Small Labor Intensity 0

Company Introduction

Meibao Group is specialized in designing and manufacturing the complete turnkey plants such as detergent powder production plant, liquid detergent plant, sodium silicate plant,soap plant,surface active agent production line,sulphonation plant,AES/SLES plant,AOS plant,mineral wool plant,hot air furnace,PE&PET plastic bottle plant,cartons plant,etc.We can provide all-in-one service for the technical consultation, R&D, planning and design, site fabrication and installation, commissioning, operators training,post-sale service and assist our customers to find the advanced technicians and high management talents.
